GMC-2016 Gantry Machining Center
Extra-wide gantry span and 5-ton table capacity for large molds and aerospace structural parts.
| Travel (X / Y / Z) | 2,000 / 1,600 / 700 mm |
|---|---|
| Table size | 2,200 × 1,400 mm |
| Spindle speed | 6,000 rpm (BT50) |
| Max. table load | 5,000 kg |
The GMC-2016 features a fixed-beam, moving-table structure with 2,000 mm of X-axis travel and a 5-ton load capacity — built for large injection molds, wind-power gearbox housings and aerospace aluminum structures.
The crossbeam and columns use low-stress, high-damping cast iron with a thermally symmetric design to minimize heat growth. An optional universal milling head enables five-sided machining in a single setup.
| Travel (X / Y / Z) | 2,000 / 1,600 / 700 mm |
|---|---|
| Table size | 2,200 × 1,400 mm |
| Spindle speed | 6,000 rpm (BT50) |
| Max. table load | 5,000 kg |
| Positioning accuracy | ±0.008 mm |
