VMC-850 Vertical Machining Center
Rigid one-piece column with linear rails on all three axes — built for high-volume precision work on 3C and automotive parts.
| Travel (X / Y / Z) | 850 / 510 / 540 mm |
|---|---|
| Table size | 1,000 × 500 mm |
| Spindle speed | 12,000 rpm (BT40) |
| Rapid traverse | 36 / 36 / 30 m/min |
The VMC-850 is a vertical machining center engineered for high-volume precision production. The one-piece resin-sand cast column and box-style base, optimized through finite element analysis, keep geometric accuracy stable even under heavy, round-the-clock cutting loads.
A 24-tool disc-type magazine, through-spindle coolant and a pre-wired 4th-axis interface come as standard; a direct-drive spindle and closed-loop linear scales are available as options. Widely used in consumer electronics, EV components and mold making.
| Travel (X / Y / Z) | 850 / 510 / 540 mm |
|---|---|
| Table size | 1,000 × 500 mm |
| Spindle speed | 12,000 rpm (BT40) |
| Rapid traverse | 36 / 36 / 30 m/min |
| Positioning accuracy | ±0.005 mm |
| Tool magazine | 24 tools (disc type) |
